ASUS
ROG STRIX Z390-H GAMING
ASUS ROG STRIX Z390-H GAMING, Intel, LGA 1151 (Socket H4), Intel® Celeron®, Intel® Pentium®, DDR4-SDRAM, DIMM, 2133,2400,2666,2800,3000,3300,3400,3466,3600,3733,3866,4000,4133,4266 MHz
ROG Strix Z390-H Gaming revitalizes the classic ROG red-and-black color scheme, adding a futuristic cyber-text pattern for a stunning modern style. It's loaded with essentials, including the latest connectivity plus intuitive ROG software optimization. All this and more makes ROG Strix Z390-H Gaming the perfect choice for all types of gamer and any level of ambition.
SOLID HARDWARE SPECS FOR GAMING AND MORE
With comprehensive cooling options and upgraded power delivery to fuel CPUs with more cores, plus support for faster memory and storage, ROG Strix Z390-H Gaming provides all the essentials you need to harness the full potential of components in your build for top-tier gaming performance.
DESIGN, CUSTOMIZATION, AND SETUP
A host of design touches, including a unique cyber-text pattern, plus customization options, comprehensive validation lists, and the most diverse ecosystem of components in the industry make building and personalizing a gaming rig with ROG Strix Z390-H Gaming wonderfully easy.
TUNE YOUR RIG THE WAY YOU WANT
The ROG Strix Z390-H Gaming motherboard features firmware controls and software utilities designed for all skill levels, making setup, tuning and system maintenance simple. With options from overclocking and cooling to managing network performance and audio characteristics, you can configure your ROG Strix gaming build to perform the way you want.
THE POWER OF INTEL
Intel Z390 chipset
The Intel® Z390 is a single-chipset design that supports Socket 1151 for 9th Gen and 8th Gen Intel® Core™, Pentium® Gold and Celeron® processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. Additionally, the chipset provides a maximum of six USB 3.1 Gen 2 ports, four USB 3.1 Gen 1 ports, and 32Gbps M.2 and PCIe 3.0 lane speed support, for faster data retrieval. Intel Z390 also supports integrated-graphics, so you'll enjoy the very latest in graphics performance.
Ready for Socket 1151 for 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® processors
This motherboard supports Socket 1151 for 9th Gen and 8th Gen Intel® Core™, Pentium® Gold and Celeron® processors, with integrated graphics, memory and PCI Express controllers to support onboard graphics output with dedicated chipsets, dual-channel (4-DIMM) DDR4 memory and 16 PCI Express 3.0/2.0 lanes for great performance.
ASUS ROG STRIX Z390-H GAMING. Processor manufacturer: Intel, Processor socket: LGA 1151 (Socket H4), Compatible processor series: Intel® Celeron®, Intel® Pentium®. Supported memory types: DDR4-SDRAM, Memory slots type: DIMM, Supported memory clock speeds: 2133,2400,2666,2800,3000,3300,3400,3466,3600,3733,3866,4000,4133,4266 MHz. Parallel processing technology support: 2-Way SLI,3-Way CrossFireX, Graphics adapter family: Intel, Graphics adapter: HD Graphics. LAN controller: Intel I219V. Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: Intel
Motherboards
| 501662 | |
| Processor | |
| Processor manufacturer: | Intel |
| Processor socket: | LGA 1151 (Socket H4) |
| Compatible processor series: | Intel® Celeron®, Intel® Pentium® |
| Memory | |
| Supported memory types: | DDR4-SDRAM |
| Number of memory slots: | 4 |
| Memory slots type: | DIMM |
| Supported memory clock speeds: | 2133,2400,2666,2800,3000,3300,3400,3466,3600,3733,3866,4000,4133,4266 MHz |
| Maximum internal memory: | 64 GB |
| Memory channels: | Dual |
| Non-ECC: | Y |
| Unbuffered memory: | Y |
| Graphics | |
| Parallel processing technology support: | 2-Way SLI,3-Way CrossFireX |
| Graphics adapter family: | Intel |
| Graphics adapter: | HD Graphics |
| Maximum resolution: | 4096 x 2160 pixels |
| Internal I/O | |
| USB 2.0 connectors: | 2 |
| USB 3.0 (3.1 Gen 1) connectors: | 2 |
| Number of SATA III connectors: | 6 |
| ATX Power connector (24-pin): | Y |
| Number of EATX power connectors: | 1 |
| CPU fan connector: | Y |
| Number of chassis fan connectors: | 2 |
| Number of COM connectors: | 1 |
| TPM connector: | Y |
| Back panel I/O ports | |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity: | 2 |
| USB 3.1 (3.1 Gen 2) Type-A ports quantity: | 4 |
| Ethernet LAN (RJ-45) ports: | 1 |
| PS/2 ports quantity: | 1 |
| HDMI ports quantity: | 1 |
| DisplayPorts quantity: | 1 |
| Headphone outputs: | 1 |
| Microphone in: | Y |
| S/PDIF out port: | Y |
| Networking | |
| Ethernet LAN: | Y |
| LAN controller: | Intel I219V |
| Features | |
| Component for: | PC |
| Motherboard form factor: | ATX |
| Motherboard chipset family: | Intel |
| Motherboard chipset: | Intel Z390 |
| Audio output channels: | 7.1 channels |
| Windows operating systems supported: | Windows 10 |
| Expansion slots | |
| Number of M.2 (M) slots: | 2 |
| BIOS | |
| BIOS type: | UEFI AMI |
| BIOS memory size: | 16 Mbit |
| ACPI version: | 6.1 |
| Clear CMOS jumper: | Y |
| Processor special features | |
| Intel® Turbo Boost Technology: | 2.0 |
| Intel Extreme Memory Profile (XMP): | Y |
| Weight & dimensions | |
| Width: | 305 mm |
| Depth: | 244 mm |
If you feel like anything is missing in these specifications, don't hesitate to contact us and raise the issue.
